HPE SERVER DL360 GEN10 5217 1P/32G NC 8SFF SVR P19176-B21 (P19176-B21)

Lifecycle

• Obsolete Date 29-02-2024
• End of support date 31-10-2028

Specifications

• Number of processors 2, maximum depending on model
• Weight 13.04 kg minimum, 16.27 kg maximum
• Security Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
• Product Dimensions (imperial) 1.69 x 17.11 x 27.83 in
• Form factor 1U
• Expansion slots 2 PCIe 3.0, for detailed descriptions reference the QuickSpecs
• NVDIMM rank N/A
• Product Dimensions (metric) 4.29 x 43.46 x 70.7 cm
• Processor cache 11 MB L3
• Processor core available 8 core
• Processor speed 3.0 GHz
• Processor Name Intel® Xeon® Scalable 5217 (8 core, 3.0 GHz, 115W)
• NVDIMM type N/A
• NVDIMM capacity N/A
• Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses)
• Network controller HPE Ethernet 1Gb 4-port 366FLR Adapter
• Processor number 1 processor
• Weight 28.74 lb minimum, 35.86 lb maximum
• Storage controller HPE Smart Array P408i-a/2 GB plus Smart Storage Battery
• Power supply type 1 HPE 800W Flex Slot Platinum hot-plug power supply
• Included hard drives None ship standard, 8 SFF drives supported
• Optical drive type None included
• System fan features 5 single rotor hot plug fans
• Warranty 3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support
• Memory, standard 32 GB (1 X 32 GB) RDIMM
• Memory type HPE DDR4 SmartMemory
