HPE SERVER DL360 GEN10 5220R 1P/32G NC 8SFF SVR P40407-B21 (P40407-B21)

Lifecycle

• Obsolete Date 29-02-2024
• End of support date 31-10-2028

Specifications

• Power supply type 1 HPE 800W Flex Slot Platinum hot-plug power supply
• Included hard drives None ship standard, 8 SFF drives supported
• Optical drive type None included
• System fan features 5 standard hot plug fans
• Storage controller HPE Smart Array S100i
• Processor Name Intel® Xeon® Scalable 5220R (24 core, 2.2 GHz, 150W)
• Processor speed 2.2 GHz
• Processor core available 24 core
• Processor cache 35.75 MB L3
• Product Dimensions (metric) 4.29 x 43.46 x 70.7 cm
• Product Dimensions (imperial) 1.69 x 17.11 x 27.83 in
• Security Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
• Weight 13.04 kg minimum, 16.27 kg maximum
• Memory, standard 32 GB (1 X 32GB) RDIMM
• Expansion slots 2 PCIe 3.0, for detailed descriptions reference the QuickSpecs
• Weight 28.74 lb minimum, 35.86 lb maximum
• Processor number 1 processor
• Number of processors 2, maximum depending on model
• NVDIMM capacity N/A
• NVDIMM type N/A
• NVDIMM rank N/A
• Memory type HPE DDR4 SmartMemory
• Network controller HPE Ethernet 10Gb 2-port FLR-T BCM57416 Adapter
• Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses)
• Warranty 3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support
• Form factor 1U
