HPE SERVER DL380 GEN10 6226R 1P/32G NC 8SFF SVR P24846
Lifecycle
- Obsolete Date 29-02-2024
- End of support date 31-10-2028
Specifications
- Expansion slots 8, for detailed descriptions reference the QuickSpecs
- Memory, standard 32 GB (1x 32GB) RDIMM
- Memory type HPE DDR4 Smart Memory with optional Intel Optane Persistent Memory for HPE
- Processor Name Intel® Xeon® Scalable 6226R (16 core, 2.9 GHz, 22 MB, 150W)
- Processor number 1
- Weight 32.6 lb
- Weight 14.76 kg
- Security Optional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
- Product Dimensions (imperial) 17.54 x 28.75 x 3.44 in
- Product Dimensions (metric) 44.55 x 73.03 x 8.74 cm
- Warranty 3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support
- Form factor 2U
- Infrastructure management HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional; requires licenses)
- Network controller 1 HPE Ethernet 10Gb 2-port 562FLR-SFP+ FlexibleLOM Adapter (665240-B21) plus optional stand-up card *NOTE: No embedded networking
- NVDIMM rank Single rank
- System fan features 4 single-rotor, standard fans included
- Included hard drives None ship standard, 8 SFF drives supported
- Optical drive type Optional
- Power supply type 1 HPE 800W Flex Slot Universal Hot Plug Low Halogen
- NVDIMM capacity 16 GB
- NVDIMM type HPE NVDIMM-N *Only available on 1st Generation Intel® Xeon® Scalable Processors
- Storage controller 1 HPE Smart Array S100i
- Processor cache 22 MB L3
- Processor core available 16, per processor
- Processor speed 2.9 GHz
