Supermicro AS -1114S-WN10RT-EU 1U Rackmount WIO SuperServer (AS -1114S-WN10RT-EU)

Favorite
Compara
Pretul afisat contine TVA (19%).

18.347,18 lei

Compara

Supermicro AS -1114S-WN10RT-EU 1U Rackmount WIO SuperServer (AS -1114S-WN10RT-EU)



Unleash the Power of AMD EPYC™ Processors

Featuring a single AMD EPYC™ 7003/7002 Series Processor, the A+ Server 1114S-WN10RT-EU offers outstanding computing performance, enabling seamless multitasking and efficient resource allocation. Experience exceptional speed and productivity for your most demanding workloads.

Compact Design, Limitless Possibilities

Housed in a sleek 1U rackmount chassis, this server combines space efficiency with uncompromising performance. Its compact form factor allows for easy integration into your existing infrastructure, saving valuable real estate while maximizing functionality.

AS -1114S-WN10RT

Unparalleled Storage Flexibility

With support for 10 hot-swappable U.2 NVMe4/NVMe3/SATA3 fully hybrid drives, the A+ Server 1114S-WN10RT-EU empowers your business with unparalleled storage flexibility. Store and access your critical data with ease, ensuring smooth operations and swift decision-making.

Reliable and Future-Proof

Built with redundancy in mind, the A+ Server 1114S-WN10RT-EU features 750W redundant power supplies, guaranteeing uninterrupted performance and mitigating potential downtime. Additionally, the server boasts 2x 10GbE LAN ports via the Broadcom BCM57416 Controller, ensuring fast and reliable network connectivity.



  • Key Features/Applications: Virtualization, Cloud Computing, All Flash Storage
  • CPU: Single AMD EPYC™ 7003/7002 Series Processor, up to 64 Cores
  • Chassis: 1U
  • Drive: Up to 10x U.2 Hot-Swap NVMe/SATA Drive Bays
  • RAM: Up to 4TB of DDR4 ECC RDIMM/LRDIMM in 16 DIMM Slots
  • Power Supply: 750W Redundant Titanium Level Power Supplies
  • Network Ports: 2x 10GbE RJ45 LAN Ports
SKU: AS -1114S-WN10RT-EU Categorii: , , , , , , , , , ,
Product SKUs
AS -1114S-WN10RT
  • Standard version with PWS-706P-1R (Platinum Level)
AS -1114S-WN10RT-EU
  • European version with PWS-861A-1R (Titanium Level)
Motherboard
Super H12SSW-NTR
Processor/Cache
CPU
  • Single AMD EPYC™ 7003/7002 Series Processor
    (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
  • Socket SP3
  • Support CPU TDP up to 280W
Cores
  • Up to 64 Cores
System Memory
Memory Capacity
  • 16 DIMM slots
  • Up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
Memory Type
  • DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
On-Board Devices
Chipset
  • System on Chip
SATA
  • SATA3 (6Gbps)
Network Controllers
  • Dual 10GBase-T LAN with via Broadcom BCM57416
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Video
  • ASPEED AST2500 BMC
Input / Output
SATA
  • 2 SATA3 (6 Gbps) ports
LAN
  • 2 RJ45 10GBase-T ports
  • 1 RJ45 Dedicated IPMI LAN port
USB
  • 7 USB 3.0 ports (4 rear, 2 front, 1 Type A)
Video
  • 1 VGA port
DOM
  • 2 SuperDOM (Disk on Module) ports
System BIOS
BIOS Type
  • AMI 256Mb SPI Flash ROM
Management
Software
  • Super Doctor 5
  • Watch Dog
  • SUM
  • IPMI 2.0, KVM with dedicated LAN
Power Configurations
  • ACPI / APM Power Management
PC Health Monitoring
CPU
  • Monitors for CPU Cores, Chipset Voltages, Memory.
  • 4+1 Phase-switching voltage regulator
FAN
  • Fans with tachometer monitoring
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
Temperature
  • Monitoring for CPU and chassis environment
  • Thermal Control for fan connectors
Chassis
Form Factor
  • 1U Rackmount
Model
  • CSE-116TS-R706WBP5-N10
Dimensions and Weight
Width
  • 17.2″ (437mm)
Height
  • 1.7″ (43mm)
Depth
  • 23.5″ (597mm)
Package
  • 7.63″ (H) 23.42″ (W) 31.45″ (D)
Weight
  • Net Weight: 25 lbs (11.34 kg)
  • Gross Weight: 39 lbs (17.69 kg)
Available Colors
  • Black
Front Panel
Buttons
  • Power On/Off button
  • UID button
LEDs
  • Power status LED
  • HDD activity LED
  • Network activity LEDs
  • Universal Information (UID) LED
Expansion Slots
PCI-Express
  • 2 PCI-E 4.0 x16 (FHHL) slots
  • 1 PCI-E 4.0* x16 (LP) slot
  • 2 PCI-E  4.0 x2 NVMe M.2 slots
  • * Limited Support: On some PCI-E 4.0 devices, it will only run at PCI-E 3.0 speed.
Drive Bays
Hot-swap
  • 10 Hot-swap U.2 NVMe4/NVMe3/SATA3 fully hybrid drive support
Backplane
Supports 10 NVMe or 10 SATA3
System Cooling
Fans
  • 6 heavy duty fans with Optimal Fan Speed Control
AC/DC240V Input Redundant Power Supply
700W/750W Redundant Power Supplies with PMBus
Note: AS -1114S-WN10RT-EU (European) SKU uses PWS-861A-1R (Titanium Level)
Total Output Power
  • 700W: 100 – 140Vac
  • 750W: 200 – 240Vac
  • 750W: 200 – 240Vdc (for CCC only)
Dimension
(W x H x L)
  • 54.5 x 40.25 x 320 mm
Input
  • 100 – 140Vac / 8 – 6A / 50-60Hz
  • 200 – 240Vac / 4.5 – 3.8A / 50-60Hz
  • 200 – 240Vdc / 4.5 – 3.8A (CCC Only)
+12V
  • Max: 58A / Min: 0.5A (100 – 140Vac)
  • Max: 62A / Min: 0.5A (200 – 240Vac)
  • Max: 62A / Min: 0.5A (200 – 240Vdc)
    (CB/CCC Only)
+5V sb
  • Max: 3A / Min: 0A
Output Type
  • Gold Finger Connector Mating with Molex 45984-4343
Certification Platinum Level Certified
Platinum Certified
[ Test Report ]
Operating Environment
RoHS
  • RoHS Compliant
Environmental Spec.
  • Operating Temperature:
    10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature:
    -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity:
    8% to 90% (non-condensing)
  • Non-operating Relative Humidity:
    5% to 95% (non-condensing)
